3.1.3 JOG/SHUTTLE Control and Select Key 37
3.1.4 Measurement Start and End
38
3.1.5 Basic Input Operation
38
3.1.6 Printer Key Operation
39
3.1.7 Other Keys Operation
39
3.1.8 On-line Help
41
3.2 Basic Measurement and Setting Procedures 42
3.2.1 Basic Operation Flow 42
3.2.2 Measuring and Recording a Voltage
(Memory Recorder Function)
43
3.2.3 Measuring and Recording a Voltage
(Recorder Function)
45
3.2.4 Measuring and Recording an RMS Value
(RMS Recorder Function)
47
Chapter 4 Memory Recorder Function 49
4.1 Outline 49
4.1.1 Outline of the Memory Recorder Function 49
4.1.2 Operation Sequence
50
4.2 Making Settings 51
4.2.1 Setting the Function Mode 51
4.2.2 Setting the Time Axis Range
52
4.2.3 Setting the Recording Length
53
4.2.4 Setting the Format
55
4.2.5 Using the X-Y Waveform Plots
57
4.2.6 Setting the Printer Format
59
4.2.7 Setting the Roll Mode
61
4.2.8 Setting the Auto Print Function
61
4.2.9 Setting the Auto Save Function
62
4.2.10 Overlay
64
4.2.11 Setting the Trigger
65
4.2.12 Input Channel Settings
65
4.3 Settings on the Display Screen 66
4.3.1 Setting Magnification/Compression Along the Time Axis 66
4.3.2 Automatic Setting of Time Axis and Voltage Axis
67
4.4 Processing Functions (Waveform Parameter Processing) 68
4.4.1 Summary of the Processing Functions 68
4.4.2 Processing Method
69
4.4.3 Waveform Parameter Calculation Details
71
