Hioki 8835-01 - Page 82

60
────────────────────────────────────────────────────
4.2 Making Settings
────────────────────────────────────────────────────
NOTE
Printing as numeric data
Method
1. Press the STATUS key to call up the STATUS
1 screen.
2. Move the flashing cursor to the print mode
item, as shown in the figure on the left.
3. Use the function keys to select numeric data.
: Waveform data and the result of calculation
are printed as a waveform.
: Waveform data and the result of calculation
are printed as numeric data.
4. Move the flashing cursor to the print interval
item.
5. Use the JOG control or the function keys to
select the print interval.
: Move the cursor up in the selection window.
: Move the cursor down in the selection
window.
When the print interval longer than the recording length is set, only the first
dot is printed.
