Displaying LACP
Settings and Status
for the Remote Side
Use the Interface > Trunk > Dynamic (Configure Aggregation Port - Show
Information - Neighbors) page to display the configuration settings and
operational state for the remote side of a link aggregation.
Parameters
These parameters are displayed:
Table 9: LACP Remote Device Configuration Information
Partner Admin System
ID
Partner Oper System
ID
Partner Admin
Port Number
Partner Oper
Port Number
LAG partner’s system ID assigned by the user.
LAG partner’s system ID assigned by the LACP protocol.
Current administrative value of the port number for the protocol Partner.
Operational port number assigned to this aggregation port by the port’s
protocol partner.
Port Admin Priority Current administrative value of the port priority for the protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding
table.)
Oper State Operational values of the partner’s state parameters. (See preceding table.)
Web Interface
To display LACP settings and status for the remote side:
1.
Click Interface, Trunk, Dynamic.
2.
Select Configure Aggregation Port from the Step list.
3.
Select Show Information from the Action list.
4.
Click Neighbors.
5.
Select a group member from the Port list.
