– 68 –
Chapter 3
|
Basic Management Tasks
Displaying Bridge Extension Capabilities
◆
Configurable PVID Tagging – This switch allows you to override the default
Port VLAN ID (PVID used in frame tags) and egress status (VLAN-Tagged or
Untagged) on each port. (Refer to “VLAN Configuration” on page 147.)
◆
Max Supported VLAN Numbers
– The maximum number of VLANs supported
on this switch.
◆
Max Supported VLAN ID
– The maximum configurable VLAN identifier
supported on this switch.
Web Interface
To view Bridge Extension information:
1. Click System, then Capability.
Figure 5: Displaying Bridge Extension Configuration
