Chapter 14 | Multicast Filtering
Filtering and Throttling MLD Groups
– 482 –
Enabling MLD
Filtering and
Throttling
Use the Multicast > MLD Snooping > Filter (Configure General) page to enable
IGMP filtering and throttling globally on the switch.
Parameters
These parameters are displayed:
◆ MLD Filter Status – Enables MLD filtering and throttling globally for the switch.
(Default: Disabled)
Web Interface
To enable MLD filtering and throttling on the switch:
1. Click Multicast, MLD Snooping, Filter.
2. Select Configure General from the Step list.
3. Enable MLD Filter Status.
4. Click Apply.
Figure 314: Enabling MLD Filtering and Throttling
Configuring MLD
Filter Profiles
Use the Multicast > MLD Snooping > Filter (Configure Profile – Add) page to create
an MLD profile and set its access mode. Then use the (Add Multicast Group Range)
page to configure the multicast groups to filter.
Command Usage
Specify a range of multicast groups by entering a start and end IPv6 address; or
specify a single multicast group by entering the same IPv6 address for the start and
end of the range.
Parameters
These parameters are displayed:
Add
◆ Profile ID – Creates an IGMP profile. (Range: 1-4294967295)
◆ Access Mode – Sets the access mode of the profile; either permit or deny.
(Default: Deny)
