Web Interface
To add rules to an IPv4 Standard ACL:
1.
Click Security, ACL.
2.
Select Configure ACL from the Step list.
3.
Select Add Rule from the Action list.
4.
Select IP Standard from the Type list.
5.
Select the name of an ACL from the Name list.
6.
Specify the action (i.e., Permit or Deny).
7.
Select the address type (Any, Host, or IP).
8.
If you select “Host,” enter a specific address. If you select “IP,” enter a subnet
address and the mask for an address range.
9.
Click Apply.
Figure 179: Configuring a Standard IPv4 ACL
Configuring an
Extended IPv4 ACL
Use the Security > ACL (Configure ACL - Add Rule - IP Extended) page to configure
an Extended IPv4 ACL.
Parameters
These parameters are displayed:
◆
Type – Selects the type of ACLs to show in the Name list.
◆
Name – Shows the names of ACLs matching the selected type.
