Direction – Displays statistics for ingress or egress traffic.
◆
Query – Displays statistics for selected criteria.
◆
ACL Name
– The ACL bound this port.
◆
Action – Shows if action is to permit or deny specified packets.
◆
Rules – Shows the rules for the ACL bound to this port.
◆
Time-Range
– Name of a time range.
◆
Hit
– Shows the number of packets matching this ACL.
◆
Clear Counter – Clears the hit counter for the specified ACL.
Web Interface
To show statistics for ACL hardware counters:
1.
Click Security, ACL.
2.
Select Configure Interface from the Step list.
3.
Select Show Hardware Counters from the Action list.
4.
Select a port.
5.
Select ingress or egress traffic.
Figure 186: Showing ACL Statistics
