LevelOne GEL-5261 - Displaying Dynamic or Local ARP Entries; Figure 326: Displaying Static ARP Entries; Figure 327: Displaying ARP Entries

Chapter 15 | IP Tools
Address Resolution Protocol
– 496 –
Figure 326: Displaying Static ARP Entries
Displaying Dynamic
or Local ARP Entries
Use the Tools > ARP page to display dynamic or local entries in the ARP cache. The
ARP cache contains static entries, and entries for local interfaces, including subnet,
host, and broadcast addresses. However, most entries will be dynamically learned
through replies to broadcast messages.
Web Interface
To display all dynamic and local entries in the ARP cache:
1. Click Tools, ARP.
2. Select Show Information from the Step List.
3. Click ARP Addresses.
Figure 327: Displaying ARP Entries
