• Remove the rubber cap and fix the antenna holder of the Antenna wire onto the Antenna connector of the

enclosure.

• Locate the patch antenna connector on the GSM/UMTS/LTE Module.

Antenna

Holder

Antenna

Wire

Patch Antenna

Connector
