• To connect your phone to a computer on your desk, use an Ethernet cable (not supplied with this phone) to
connect the PC Port of the phone with LAN Port of the computer.
• It is a PoE enabled phone and can be powered over Ethernet by connecting it to a PoE enabled LAN
Switch (IEEE 802.3af Compliant). In this case you need not connect the Power Adapter.
If you do not want to use PoE, plug in the connector of the Adapter into the power jack (DC Jack) at the
bottom of the phone. Plug in the Power Adapter into a power outlet.
• If both the power options, that is, PoE as well as Power Adapter are available to the phone, then the
phone will derive power from the PoE enabled LAN Switch.
• The IP phone should be used with Matrix original power adapter (5V/2A) only. The use of any third-
party power adapter may cause damage to the phone.
• Switch ON power supply.
When you power the phone, the boot process will be initiated in the following sequence.
• All keys with LED, including the Speaker key and the Ringer LED will glow.
• The LCD display will light up and booting message appears.
• As soon as the ‘Loading...’ message appears on the phone display, press # key.
• Select the firmware Extended - IP Phone. Move the cursor by pressing the DOWN navigation key V.
• When the cursor is placed under the Extended IP Phone, press Enter key.
• The phone will start loading the Extended IP Phone Firmware. It will display current firmware being loaded.
• After loading the firmware, the phone will prompt you to change Network settings.
• Wait for a few seconds.
Select the firmware
Standard S IP
Extended S IP
C h a n g e N e t w o r k S e t t i n g s ?
To Next Page
Loading...
