• To send an SMS, user taps Message .
• The system will check if the SMS is sent by a SIP extension. If it is a SIP extension, then it checks if the
SMS over IP option is enabled for the SIP extension. If it is enabled then the SMS will be sent using the
desired Mobile Port. The Mobile Port using which the SMS will be sent to the destination will depend on the
configurations— Fixed/LCR— in SMS over IP Settings.
• When the SMS is received on Mobile Port, the system checks the Send SMS and the Call Budget
parameters configured for the Mobile Port.
If Send SMS is disabled or the Call Budget exceeds the SMS will be rejected.
If Send SMS is enabled and the Call Budget has not exceeded, the system checks the senders number in
the Denied numbers list as configured in the SMS over IP Settings.
• If a match is found in the Denied list, the SMS will be rejected. If no match is found, then it checks the
destination where the SMS is to be delivered. The destination can be an Extension Number/ External
Number or Name.
When the destination is an Extension Number/Name the system will search for the Extension Number in its
database and then send an SMS to its corresponding Mobile Number.
When the destination is a Mobile number the system will send the SMS to this Mobile number.
• The senders Name and/or Number will be displayed to the recipients, if you have enabled Add Footer in
SMS and configured the parameter Footer text.
It is recommended that you configure the parameters Add Footer in SMS and Footer text, so that the
recipient knows the sender of the message. If this parameter is not configured, only the mobile port SIM
number will be displayed to the recipient.
How to configure
You need to configure the following SMS over IP parameters,
• Login as System Engineer.
• Under Basic Settings, click VoIP Parameters.
• Click SMS over IP Settings.
• Configure the following parameters:
• You can Send SMS through certain fixed Mobile Ports or through different Mobile Ports according to
specific numbers and time.
To send messages through fixed Mobile Ports, select Using Fixed Port and configure the SMS
over IP - Fixed Port Routing table. For detailed information, see “Fixed Port Routing (SMS over
IP)”.
