Creating a VNIC Without a VLAN ID for Clustered Controllers (BUI)
10.
Click "APPLY". The interface will appear in the Interfaces list.
11.
The running appliance network configuration has not yet changed. When you
are finished configuring interfaces, click "APPLY" at the top to commit the
configuration.
Creating a VNIC Without a VLAN ID for Clustered Controllers
(BUI)
This example is for an active-active configuration with half of the network ports on standby.
This task creates an IP interface over a device datalink and assigns it to a head. A VNIC is built
on top of the same datalink, and an IP interface is configured on top of the VNIC and assigned
to the other head. Configuring one instead of multiple VNICs over a given datalink ensures
peak performance. Traffic flows over the cable associated with the underlying active port on
one head, as well as the underlying standby port on the other head. Thus, the otherwise idle
standby port can be used with VNICs.
1.
When the cluster is in state AKCS_CLUSTERED, click the Datalinks icon.
2.
Optionally, set name and MTU.
3.
Choose a device from the Devices list and click "APPLY". The datalink appears
in the Datalinks list.
4.
Click the Interface icon.
5.
Set desired properties, choose the datalink previously created, and click
"APPLY". The interface appears in the Interfaces list.
6.
Click the Datalinks icon.
7.
Select the VNIC checkbox, optionally set name and MTU (equal to or less than
the value in step 2), and click "APPLY". The new VNIC datalink appears in the
Datalinks list.
8.
Click the Interface icon.
9.
Set desired properties, choose the VNIC datalink previously created, and click
"APPLY". The interface appears in the Interfaces list.
66 Oracle ZFS Storage Appliance Administration Guide, Release OS8.6.x • September 2016
