Parameter Description
Example: \%n\%y%M%d\%h%m%s
Available only when the DateTimePrefixFileName=true
Language Select the language to use. When empty, dump will execute on all languages.
Available only when the EventArchive is an alarms buffer
Example
When exporting Event buffers in binary format and DumpConfigFile is set to true (recommended settings), there are two
folders:
l data, containing data files,
l config, containing configuration files for .csv conversion.
Once the two folders are copied from the USB drive to the computer disk, the folder structure will be:
\config\
alarms.xml
eventconfig.xml
\data\
AlarmBuffer1.dat
AlarmBuffer1.inf
\
AlarmBufferReader.exe
To convert dump files to .csv
The AlarmBufferReader.exe tool is stored in the Utils folder of the HMWIN Studio installation folder.
Use the following syntax:
AlarmBufferReader AlarmBuffer1 FILE ./AlarmBuffer1.csv
where:
AlarmBuffer1 = name of the dumped .dat without extension
AlarmBuffer1.csv = name for the output file.
The utility AuditTrailBufferReader.exe is available for Audit Trail buffers.
Note: set DumpConfigFile to true.
The result of the dump is a folder structure similar to the one generated for Events.
Use the following syntax:
140
HMWIN Studio |User Manual|v206 (2017-06-30) |EN|© 2014-2017 Panasonic Electric Works Europe AG
