PerkinElmer LabChip GX User Manual

Software Reference 186
V4.2 LabChip GX User Manual PerkinElmer
Assay Analysis Window
The Assay Analysis window specifies the analysis parameters.
These settings are used to display assay settings and change the
analysis and peak finding parameters to help resolve hard-to-
decipher data. To open the Assay Analysis window, select Analysis
 Analysis Settings on the main menu.
The Assay Analysis window contains the following tabs:
• Assay Information Tab
• Alignment Tab
• Analysis Tab
• Peak Find Tab
• Expected Fragments/Proteins/Glycans Tab
• Excluded Peaks Tab
• Smear Analysis Tab
• Titer Tab
• Advanced Tab
The following buttons at the bottom of the Assay Analysis window
are used to save, apply, or cancel changes:
Buttons Function
Apply Apply setting changes and re-analyze the plate but keep the Assay
Analysis window open.
Apply
Global
Applies the selected analysis settings to all plates in the open
workspace.
Export As
Assay
Opens the Export Assay Settings from Plate to Assay file window to
specify a name and location for a new assay file (*.asy or *.asyx).
Clicking Save creates a new assay file with the settings in the Assay
Analysis Window.
Restore
Plate
Opens the Restore Plate Settings To Version window to restore the data
file to the selected version.
OK Apply changes in the Assay Analysis window and re-analyze the plate
with these new settings.
Print
Preview
Opens the Print Preview window to view the analysis settings before
printing.
Print Opens the Print window to print the analysis settings.
Cancel Restores the settings that were selected when the window was opened
or when the last Apply was performed. No re-analysis is performed
because the settings were used for the last analysis performed.
