Teach Robot Window
The Teach Robot Window displays instructions on preparing the
robot for teaching the reference position.
Figure 103. Teach Robot Window
The Teach Robot Window contains:
Option/Button Function
Back button Displays the Welcome Window.
Next button Displays the Teach the X, Y and Z Reference Positions
Window. Follow the instructions in the window before clicking
the Next button.
Cancel button Closes the Robot Teach Wizard without saving changes to any
positions.
