PerkinElmer LabChip GX User Manual

Software Reference 245
V4.2 LabChip GX User Manual PerkinElmer
Sample Name Editor Window
Use the Sample Name Editor window to specify names for the
samples in the plate. For DNA, Protein, Glycan, CZE, and gDNA
assays, also can be used to view, add, edit, or delete expected
peaks. Sample Names can be exported to a .CSV file to be re-used
in other workspaces or for other plates.
To open the Sample Name Editor window, choose Tools  Sample
Name Editor on the LabChip GX Main Window or click the Edit
button next to the Sample Name File text box on the Advanced Tab
in the Start Run Window after selecting the Sample Name File.
Figure 112. Sample Name Editor Window
Edit Expected Peaks check box - If selected, displays the
Expected Peaks and Window (%) columns for DNA, Protein,
Glycan, CZE, and gDNA assays. This option is not available for
RNA assays.
The following columns display in the Sample Name Editor window:
Column Description
Well Label Displays the row letter and column number of each well. Wells
are ordered by column if the Order by Column check box is
selected. If the window is opened from the Start Run Window, the
wells display by column or well depending on the selection on the
Run tab. If a plate is running when the window is opened, the
wells display by column or well based on the sip order of the
currently running plate.
