Software Reference 241
V4.2 LabChip GX User Manual PerkinElmer
Verify All Target Positions Window
Use the Verify All Target Positions Window to skip teaching the
reference positions and verify the plate, buffer vial, and ladder vial
positions. Select the Verify Target Positions Only check box on the
Welcome Window and click the Next button to open the Verify All
Target Positions Window.
Figure 108. Verify All Target Positions Window
The Verify All Target Positions Window contains the following
options and buttons:
Option/Button Function
Plate Name list Displays the names of the plates that have been created for
use in the instrument.
View Plate Info
button
Opens the Plate Information Window to view existing plates or
to add new plates.
Back button Displays the Welcome Window.
Next button Displays the Verify All Target Positions Correct Window.
Cancel button Closes the Robot Teach Wizard without saving changes to any
positions.
