Software Reference 254
V4.2 LabChip GX User Manual PerkinElmer
Output Tab (Continued)
Automatic Export
If selected, data is automatically exported at the end of each run.
Select the type of data to export by clicking the Settings button and
choosing the desired settings in the Export Window. For more
information, see Exporting Data.
Advanced Tab
Use the Advanced tab on the Start Run Window to select the
number of plate cycles, the sample saver options, the Sample
Names file, the Expected Peaks file, and the Excluded Peaks file.
Figure 118. Start Run Window - Advanced Tab
The Advanced tab contains the following options:
Plate Cycles
Specifies how many times to repeat the same assay on the plate.
Random Selection %
If selected, the instrument will randomly sample the specified
percent of wells from the selected wells. For example, if 10 wells
are selected, and the Random Selection percent is set to 50%, five
wells, selected at random, will be sampled during the run.
To Next Page
