Siemens Simatic S7 Series System Manual

Communication
8.5 PROFIBUS
S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
389
GSD file for the EM DP01 PROFIBUS-DP
MLFB: 6ES7 288-7DP01-0AA0
Table 8- 6 General parameters
Parameters
Values
#Profibus_DP
GSD_Revision = 5
Vendor_Name
= "Siemens"
Model_Name
= "EM DP01 PROFIBUS-DP"
Revision
= "V01.00.00"
Ident_Number
= 0x81C7
Protocol_Ident
= 0
Station_Type
= 0
FMS_supp
= 0
Hardware_Release
= 1
Software_Release
= "V01.00.00"
;
9.6_supp
= 1
19.2_supp
= 1
45.45_supp
= 1
93.75_supp
= 1
187.5_supp
= 1
500_supp
= 1
1.5M_supp
= 1
3M_supp
= 1
6M_supp
= 1
12M_supp
= 1
;
MaxTsdr_9.6
= 40
MaxTsdr_19.2 = 40
MaxTsdr_45.45
= 40
MaxTsdr_93.75
= 40
MaxTsdr_187.5
= 40
MaxTsdr_500
= 40
MaxTsdr_1.5M
= 40
MaxTsdr_3M
= 50
MaxTsdr_6M
= 100
MaxTsdr_12M
= 200
;
Redundancy
= 0
Repeater_Ctrl_Sig
= 2
24V_Pins
= 2

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
