Communication
8.5 PROFIBUS
S7-200 SMART
390 System Manual, 09/2015, A5E03822230-AC
Parameters
Values
Implementation_Type
= "DPC31"
Bitmap_Device = "EM_DP01N"
Table 8- 7 Slave-Specification
Parameters
Values
OrderNumber
= "6ES7 288-7DP01-0AA0"
Periphery = "SIMATIC S7"
Info_Text
= "PROFIBUS module for SMART CPU family."
Slave_Family
= 10@TdF@SIMATIC
Freeze_Mode_supp
= 1
Sync_Mode_supp
= 1
Set_Slave_Add_Supp
= 0
Auto_Baud_supp
= 1
Min_Slave_Intervall
= 1
Fail_Safe
= 0
;
Modular_Station
= 1
Max_Module
= 2
Modul_Offset
= 0
;
Max_Input_len
= 244
Max_Output_len
= 244
Max_Data_len
= 488
Max_Diag_Data_Len
= 6
