Siemens Simatic S7 Series System Manual

Special memory (SM) and system symbol names
D.15 SMB66-SMB85, SMB166-SMB169, SMB176-SMB179, and SMB566-
SMB579: PTO0, PWM0, PTO1, PWM1, PTO2,
S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
679
S7-200 SMART
symbol name
SM address
Function
PTO0_Operation
SM67.5
PTO0 select single/multiple segment operation: 0=single; 1=multiple
PLS0_Select SM67.6 PTO0/PWM0 mode select: 0=PWM; 1=PTO
PLS0_Enable
SM67.7
PTO0/PWM0 enable: 0=disable; 1=enable
PLS0_Cycle
SMW68
Word data type: PWM0 cycle time value (2 to 65,535 units of time base);
PTO0 frequency value (1 to 65,535 Hz)
PWM0_PW
SMW70
Word data type: PWM0 pulse width value (0 to 65,535 units of time base)
PTO0_PC
SMD72
Double Word data type: PTO0 pulse count value (1 to 2^31 - 1)
PTO0_Seg_Num
SMB166
Byte data type: The currently executing segment number for PTO0's
profile
PTO0_Profile_Offset
SMW168
Word data type: Starting location of PTO0's profile table (byte offset from
V0)
Table D- 14 High-speed output 1 configuration and control
S7-200 SMART
symbol name
SM address
Function
PTO1_Status
SMB76
PTO1 Status
PLS1_Abort_AE
SM76.4
PTO1 profile was aborted due to an add error: 0=no abort; 1=aborted
PLS1_Disable_UC SM76.5 PTO1 user manually disabled a PTO profile while it was running: 0=not
disabled; 1=manually disabled
PLS1_Ovr SM76.6 PTO1 pipeline overflow/underflow, loading pipeline while full or transfer-
ring an empty pipeline: 0=No overflow; 1=Pipeline overflow/underflow
PLS1_Idle
SM76.7
PTO1 idle: 0=PTO in progress; 1=PTO is idle
PLS1_Ctrl
SMB77
Monitor and control PTO1 (Pulse Train Output) and PWM1 (Pulse Width
Modulation) for Q0.1
PLS1_Cycle_Update SM77.0 PTO1/PWM1 update the cycle time or frequency value: 0=no update; 1=
write new cycle time/frequency
PWM1_PW_Update SM77.1 PWM1 update the pulse width value: 0=no update; 1= write new pulse
width
PTO1_PC_Update SM77.2 PTO1 update the pulse count value: 0=no update; 1= write new pulse
count
PWM1_TimeBase
SM77.3
PWM1 time base: 0=1 μs/tick, 1=1 ms/tick
SM77.4
Reserved
PTO1_Operation
SM77.5
PTO1 select single/multiple segment operation: 0=single; 1=multiple
PLS1_Select
SM77.6
PTO1/PWM1 mode select: 0=PWM; 1=PTO
PLS1_Enable
SM77.7
PTO1/PWM1 enable: 0=disable; 1=enable
PLS1_Cycle
SMW78
Word data type: PWM1 cycle time value (2 to 65,535 units of time base);
PTO1 frequency value (1 to 65,535 Hz)
PWM1_PW
SMW80
Word data type: PWM1 pulse width value (0 to 65,535 units of time base)
PTO1_PC
SMD82
Double Word data type: PTO1 pulse count value (1 to 2^31 - 1)
PTO1_Seg_Num
SMB176
Byte data type: The currently executing segment number for PTO1's
profile
PTO1_Profile_Offset
SMW178
Word data type: Starting location of PTO1's profile table (byte offset from
V0)
