Siemens Simatic S7 Series System Manual

Special memory (SM) and system symbol names
D.15 SMB66-SMB85, SMB166-SMB169, SMB176-SMB179, and SMB566-SMB579: PTO0, PWM0, PTO1,
PWM1, PTO2, and PWM2 high-speed outputs
S7-200 SMART
680 System Manual, 09/2015, A5E03822230-AC
Table D- 15 High-speed output 2 configuration and control
S7-200 SMART
symbol name
SM address
Description
PTO2_Status
SMB566
PTO2 Status
PLS2_Abort_AE SM566.4 PTO2 profile was aborted due to an add error: 0=no abort; 1=aborted
PLS2_Disable_UC SM566.5 PTO2 user manually disabled a PTO profile while it was running: 0=not
disabled; 1=manually disabled
PLS2_Ovr SM566.6 PTO2 pipeline overflow/underflow, loading pipeline while full or transfer-
ring an empty pipeline: 0=No overflow; 1=Pipeline overflow/underflow
PLS2_Idle
SM566.7
PTO2 idle: 0=PTO in progress; 1=PTO is idle
PLS2_Ctrl
SMB567
Monitor and control PTO2 (Pulse Train Output) and PWM2 (Pulse Width
Modulation) for Q0.3
PLS2_Cycle_Update SM567.0 PTO2/PWM2 update the cycle time or frequency value: 0=no update; 1=
write new cycle time/frequency
PWM2_PW_Update SM567.1 PWM2 update the pulse width value: 0=no update; 1= write new pulse
width
PTO2_PC_Update SM567.2 PTO2 update the pulse count value: 0=no update; 1= write new pulse
count
PLS2_TimeBase
SM567.3
PWM2 time base: 0=1 μs/tick, 1=1 ms/tick
SM567.4
Reserved
PTO2_Operation
SM567.5
PTO2 select single/multiple segment operation: 0=single; 1=multiple
PLS2_Select
SM567.6
PTO2/PWM2 mode select: 0=PWM; 1=PTO
PLS2_Enable
SM567.7
PTO2/PWM2 enable: 0=disable; 1=enable
PLS2_Cycle
SMW568
Word data type: PWM2 cycle time value (2 to 65,535 units of time base);
PTO2 frequency value (1 to 65,535 Hz)
PWM2_PW
SMW570
Word data type: PWM2 pulse width value (0 to 65,535 units of time base)
PTO2_PC
SMD572
Double Word data type: PTO2 pulse count value (1 to 2^31 - 1)
PTO2_Seg_Num
SMB576
Byte data type: The currently executing segment number for PTO2's
profile
PTO2_Profile_Offset
SMW578
Word data type: Starting location of PTO2's profile table (byte offset from
V0)
