Tektronix MSO56 User Manual

Commands listed in alphabetical order
Examples
BUS:B1:AUDio:
FRAME:CLOCKBITSPERCHANNEL 32
sets the number of bits
to 32.
BUS:B1:AUDio
:FRAME:CLOCKBITSPERCHANNEL ?
might return
:BUS:B1:AUDIO:FRAME:CLOCK BITSPERCHANNEL 24 indicating there are 24
bits of sync width for the bus.
BUS:B<x>:A
UDio:FRAME:SIZe
This command sets or queries the number of audio channels in each frame for the
specified AUDIO bus. The bus is specified by x.
NOTE. Thi
s command only applies to the TDM Audio type.
Conditions
Requires option S R-AUDIO.
Group
Bus
Syntax
BUS:B<x>:AUDio:FRAME:SIZe <NR1>
BUS:B<x>:AUDio:FRAME:SIZe ?
Arguments
<NR1> specifies the number of channels in each frame.
Examples
BUS:B1:AUDIO:FRAME:SIZE 2 sets the frame size to 2.
BUS:B1:AUDIO:FRAME:SIZE? might return :BUS:B1:AUDIO:FRAME:SIZE 8
indicating that the number of channels in each frame is set to 8.
BUS
:B<x>:AUDio:TYPe
This command sets or queries the audio format (type) for the specified audio
bus. The bus is specified by x.
Conditions
Requires option S R-AUDIO.
Group
Bus
Syntax
BUS:B<x>:AUDio:TYPe {I2S|LJ|RJ|TDM}
BUS:B<x>:AUDio:TYPe?
2-124 MSO54, MSO56, MSO58, MSO58LP Programmer
