Tektronix MSO56

Commands listed in alphabetical order
Examples
DISplay:WAVEV
iew1:CH1_DALL:VERTical:POSit ion 1.0e0
sets the
vertical position to 1.0 divisions.
DISplay:WAVE
View1:CH1_DALL:VERTical:PO Sition?
might return
:DISPLAY:WAVEVIEW1:CH1_DA LL:VERTICAL:POSITION 0.0E +0 indicating
the vertical position is 0.0 divisions.
DISplay:WA
VEView<x>:CH<x>_D<x>:STATE
This command sets or queries the display state of the specified digital channel in
the specified waveview.
Group
Display Control
Syntax
DISplay:WAVEView<x>:CH<x> _D<x>:STATE {<NR1>|OFF|ON }
DISplay:WAVEView<x>:CH<x> _D<x>:STATE?
Arguments
<NR1> = 0 disables the display of the specified channel on the specified waveview;
any other value turns this feature on.
OFF disables the display of the specified channel on the specified waveview.
ON enables the display of the specified channel on the specified waveview.
Examples
DISplay:WAVEView1:CH1_D1: STATE OFF turns off the specified digital
channel.
DISplay:WAVEView1:CH1_D1: STATE? might return
:DISPLAY:WAVEVIEW1:CH1_D1 :STATE 1 indicating the specified digital
channel is on.
DISplay:WAVEView<x>:CURSor? (Query Only)
This query returns the cursor parameters for the specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSo r?
2-286 MSO54, MSO56, MSO58, MSO58LP Programmer
