Tektronix MSO56 User Manual

Commands listed in alphabetical order
Syntax
MEASUrement:M
EAS<x>:REFLevels<x>:ABSolute :FALLLow <NR3>
MEASUrement:MEAS<x>:REFLe vels<x>:ABSolute:FALLLow?
Arguments
<NR3> is the low reference level in volts. The default is 0 .0 V.
Examples
MEASUREMENT:MEAS1:REFLEVE LS1:ABSOLUTE:FALLLOW 0.0 V sets the
low reference level to 0.0 V.
MEASUREMENT:MEAS1:REFLEVE LS1:ABSOLUTE:FALLLOW? might return
:MEASUREMENT:MEAS1:REFLEV ELS1:ABSOLUTE:FALLLOW 0.0 000E+00,
indicating that the absolute low reference level is set to 0.0 V.
MEASUrement:MEAS<x>:REFLevels<x>:ABSolute:FALLMid
This command sets o r queries the value used as the mid reference level of
the falling edge when the measurement's ref level method is set to absolute.
Measurements are specified by x.
NOTE. This command affects the results of period, frequency, delay, and all
cyclic measurements.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:REFLe vels<x>:ABSolute:FALLMid <NR3>
MEASUrement:MEAS<x>:REFLe vels<x>:ABSolute:FALLMid?
Argu
ments
<NR3> is the mid reference level in volts. The default is 0.0 V.
Examples
MEASUREMENT:MEAS1:REFLEVE LS1:ABSOLUTE:FALLMID 0.5 sets the mid
reference level for the delay waveform to 0.5 V.
MEASUREMENT:MEAS1:REFLEVE LS1:ABSOLUTE:FALLMID? might return
:MEASUREMENT:MEAS1:REFLEV ELS1:ABSOLUTE:FALLMID 0.5 000E+00,
indicating that the absolute mid reference level is set to 0.5 V.
MEASUrement:MEAS<x>:REFLevels<x>:ABSolute:HYSTeresis
This command sets or queries the value of the hysteresis of the reference level
when the measurement's ref leve
l method is set to absolute. The measurement
number is specified by x.
2-470 MSO54, MSO56, MSO58, MSO58LP Programmer
