Command groups

Bus command group

Use the commands in the Bus Command Group to conﬁgure a bus. These

commands let you:

Specify the bus type.

Specifythesignalstobeusedinthebus.

Specify its display style.

NOTE. Bus commands are present once a bus has been added.

Bus Mnemonics

Commands specify the bus to use as a mnemonic in the header.

Table 2-20: Bus mnemonics

Symbol Meaning

B<x>

A bus speciﬁer; <x> is ≥1.

Table 2-21: Bus commands

Command Description

BUS:ADDNew Adds the speciﬁed bus.

BUS:B<x>:ARINC429A:SOUrce Sets or queries the source for the speciﬁed ARINC429 bus.

BUS:B<x>:ARINC429A:THRESHold Sets or queries the ARINC429 upper threshold for the speciﬁed bus.

BUS:B<x>:ARINC429A:POLARITY Sets or queries the source polarity for the speciﬁed ARINC429 bus.

BUS:B<x>:ARINC429A:DATAFORmat Sets or queries the format of the DATA ﬁeld for the speciﬁ ed ARINC429 bus.

BUS:B<x>:ARINC429A:BITRate Sets of queries the ARINC429 bit rate for the speciﬁed bus.

BUS:B<x>:ARINC429A:BITRate:CUSTom Sets or queries the ARINC429 custom bit rate for the speciﬁed bus.

BUS:B<x>:AUD io:BITDelay Sets or queries the number of delay bits for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:BITOrder Speciﬁes the bit order for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:C LOCk:POLarity Sets or queries the clock polarity for the speciﬁed AUDIO bus.

BUS:B<x>:AUD io:C LOC k:SOUrce Sets or queries the clock source waveform for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:CLOCk:THReshold Sets or queries the Audio Clock source threshold for the speciﬁed bus.

BUS:B<x>:AUDio:DATa:POLarity Speciﬁes the data polarity for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:DATa:SIZe Speciﬁes the number of bits per word for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:DATa:SOUrce Speciﬁes the audio data source waveform for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:DATa:THReshold Sets or queries the Audio D ata source threshold for the speciﬁed bus.

BUS:B<x>:AUDio:DATa:WORDSize Sets or queries the Audio bits per word for the speciﬁed bus.

BUS:B<x>:AUDio:FRAME:

CLOCKBITSPERCHANNEL

Sets or queries the Audio bits of sync width for the speciﬁed bus.

BUS:B<x>:AUD io:F RAME:SIZe Speciﬁes the number of channels in each frame for the speciﬁed AUDIO bus.

BUS:B<x>:AUDio:TYPe Speciﬁes the audio format (type) for the speciﬁed AUDIO bus.

2-14 MSO54, MSO56, MSO58, MSO58LP Programmer
