Commands listed in alphabetical order
TRIGger:{A|B
}:BUS:B<x>:ARINC429A:DATa:QUALifier
This command sets or queries the qualifier to be used when triggering on data in
the DATA field for an ARINC429 bus signal. The bus number is specified by x.
The trigger c
ondition must be set to DATa or LABELANDDATA.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Trigger
Syntax
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:DATa:
QUALifier
{EQual|UNEQual|LESSthan|MOREthan
|LESSEQual|MOREEQual|INrange|OUTrange}
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:DATa:QUALifier?
Arguments
Argumentsaretheavailabledataqualifiers.
NOTE. The trigger qualifier only applies to the bits defined as the data field via
the bus data field format specifier (using
BUS:B<x>:ARI NC429A:DATAFORmat )
Examples
TRIGGER:A:BUS:B1:ARINC429A :DATA:QUALIFIER LES
STHAN
sets the data
qualifier to less than.
TRIGGER:A:BUS:B1:ARINC429A :DATA:QUALIFIER? m
ight return EQUAL,
indicating that the data qualifier is set to equal.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:DATa:VALue
This command sets or queries the low value when triggering on an ARINC429
data field. The bus number is specified by x. The trigger condition must be set to
DATa or LABELANDDATA.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Trigger
Syntax
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:DATa:VALue <QString>
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:DATa:VALue?
MSO54, MSO56, MSO58, MSO58LP Programmer 2-761
