Command groups
Plot command group
Plot commands let y ou select the type and control the appearance of your plots.
Table 2 -33: Plot commands
Command
Description
PLOT:ADDNew Adds the specified plot.
PLOT:DELete Deletes the specified plot.
PLOT:LIST? Lists all currently defined plots.
PLOT:PLOT<x>:BATHtub:BER Sets or queries the bathtub BER value.
PLOT:PLOT<x>:BATHtub:XAXISUnits Sets or queries the X-Axis unit, either unit i ntervals or seconds.
PLOT:PLOT<x>:LAB el:COLor Sets or queries the color of the specified trend label.
PLOT:PLOT<x>:LAB el:FO NT:BOLD Sets or queries the bold s tate of the specified trend label.
PLOT:PLOT<x>:LABel:FONT:ITALic Sets or queries the italic state of the speci fied trend label.
PLOT:PLOT<x>:LAB el:FO NT:SIZE Sets or queries the font size of the specified trend label.
PLOT:PLOT<x>:LAB el:FONT:TYPE Sets or queries the font type of the s pecified trend label.
PLOT:PLOT<x>:LAB el:FO NT:UNDERline Sets or queries the underline state of the specifi ed trend label.
PLOT:PLOT<x>:LAB el:NAMe Sets or queries the specified trend's label.
PLOT:PLOT<x>:LAB el:XPO S Sets or queries the x-position of the specified trend label.
PLOT:PLOT<x>:LAB el:YPO S Sets or queries the y-position of the specified trend label.
PLOT:PLOT<x>:NUMBins Sets or queries the current histogram resolution.
PLOT:PLOT<x>:SO Urce<x> Sets or queries the measurement source.
PLOT:PLOT<x>:SP ECtrum:BASE Sets or queries the spectrum base. Undefined for non-spectrum plots.
PLOT:PLOT<x>:SP ECtrum:DY NRange Sets or queries the dynamic range value.
PLOT:PLOT<x>:TYPe Sets or queries the current plot type for the selected plot.
Power command group
Table 2 -34: Power commands
Command Description
POWer:ADDNew Adds the specified power measurement badge.
POWer:DELete Deletes the specified power measurement badge.
POWer:POWer<x>:AUTOSet Executes power autoset for the specified power measurement badge.
POWer:POWer<x>:CYCLEAmp:
INPUTSOurc e
Sets or queries the input source for cycle amplitude measurement in the specified power
measurement badge.
POWer:POWer<x>:CYCLEBase:
INPUTSOurc e
Sets or queries the input source for cycle base m easurement in the specified power
measurement badge.
POWer:POWer<x>:CYCLEMAX:
INPUTSOurc e
Sets or queries the input source for cycle maximum measurement in the specified power
measurement badge.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-55
