Tektronix MSO56 User Manual

Commands listed in alphabetical order
Examples
MEASUrement:M
EAS1:POPUlation:LIMIT:VALue 2000
sets the population
limit to 2000.
MEASUrement:
MEAS1:POPUlation:LIMIT:VAL ue?
might return
:MEASUREMENT:MEAS1:POPULAT ION:LIMIT:VALUE 1000 indicating the limit
is set to 1000.
MEASUremen
t:MEAS<x>:REFLevels:ABSolute:FALLHigh
This command sets or queries the value used as the high reference level of
the falling edge when the measurement's ref level method is set to absolute.
Measurem
ents are specified by x.
NOTE. This command affects the results of rise and fall measurements
Group
Measure
ment
Syntax
MEASUrement:MEAS<x>:REFLev els:ABSolute:FALLHigh <NR 3>
MEASUrement:MEAS<x>:REFLev els:ABSolute:FALLHigh?
Arguments
<NR3> is the high reference level in volts. The default is 0.0 V.
Examples
MEASUREMENT:MEAS1:REFLEVEL S:ABSOLUTE:FALLHIGH 1.71 sets the high
reference level to 1.71 V.
MEASUREMENT:MEAS1:REFLEVEL S:ABSOLUTE:FALLHIGH? might return
:MEASUREMENT:MEAS1:REFLEVE LS:ABSOLUTE:FALLHIGH 1.71 00E+00,
indicating that the absolute high reference level is set to 1.71 V.
MEASUrement:MEAS<x>:REFLevels<x>:ABSolute:FALLLow
This command sets or queries the value used as the low reference level of
the falling edge when the measurement's ref level method is set to absolute.
Measurements are specified by x.
NOTE. This command affects the results of rise and fall measurements.
Group
Measurement
MSO54, MSO56, MSO58, MSO58LP Programmer 2-469
