Commands listed in alphabetical order
Syntax
DISplay:WAVEV
iew<x>:CURSor:CURSOR<x>:HBAr s:DELTa?
Returns
The delta V cursor readout value of the specified cursor in the specified waveview.
Examples
DISplay:WAVEView1:CURSor:C URSOR1:HBArs:DELTa? might return
:DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:HBARS:DELTA 2.612 085129310
indicating the delta between the cursors is 2.61 V.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:MODe
Sets or queries the cursor tracking mode of the specified cursor in the specified
waveview.
NOTE.
WAVEView<x > is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSor :CURSOR<x>:MODe
{INDEPENDENT|TRACK}
Arguments
TRACK ties the navigational functionality of the two cursors together. For cursor 1
adjustments, this ties the movement of the two cursors together; however, cursor 2
continues to move independently of cursor 1.
INDEPENDENT allows independent adjustment of the two cursors.
Examples
DISPLAY:WAVEVIEW1:CURSOR:C URSOR1:MODE TRACK specifies that the
cursor positions move in unison.
DISPLAY:WAVEVIEW1:CURSOR:C URSOR1:MODE? might return
:
DISPLAY:WAVEVIEW1:CURSOR:C URSOR1:MODE TRACK, indicating that the
two cursors move in unison.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:ONEOVERDELTATVALU
E? (Query
Only)
This query returns the one over delta T cursor readout value of t
he specified
cursor in the specified waveview.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-293
