Commands listed in alphabetical order
"???? ????";:D
ISPLAY:WAVEVIEW1:CURSOR:CURSOR:STATE
1;FUNCTION WAVEFORM;SCREEN:AYPOSITION
-2.0E-3;BXPOSITION -5.0E-6;BYPOSITION -2.0E-3;AXPOSITIO N
-5.0E-6;:DISPLAY:WAVEVIEW1:CURSOR:CURSOR:MODE
INDEPENDENT;ASOURCE AUTO;DDT
9.91E+37;ONEOVERDELTATVALUE 100.0E+3;SPLITM ODE
SAME;LINES
TYLE SOLID.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:ASOUrce
This command sets or queries the cursor A source of the specified cursor in the
specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:ASOUrce
{AUTO|CH<x>|BUS<x>|MATH<x >| REF<x>|PLOT<x>}
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:ASOUrce?
Arguments
Arguments are the specified source waveform.
Examples
DISplay:WAVEView1:CURSor: CURSOR1:ASOUrce CH1 sets the c ursor 1
source to channel 1.
DISplay:WAVEView1:CURSor: CURSOR1:ASOUrce? might return
:DISPLAY:WAVEVIEW1:CURSOR :CURSOR1:ASOURCE REF1 indicating the
cursor A source is referen ce 1.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:BSOUrce
This command sets or queries the cursor B source of the specified cursor in the
specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
2-288 MSO54, MSO56, MSO58, MSO58LP Programmer
