Tektronix MSO56

Commands listed in alphabetical order
Examples
DISplay:WAVEV
iew1:MATH:MATH1:VERTical:POS ition 0
sets the position
to 0 divisions.
DISplay:WAVE
View1:MATH:MATH1:VERTical: POSition?
might return
:DISPLAY:WAVEVIEW1:MATH:MA TH1:VERTICAL:POSITION -2. 2800
indicating the position is at -2.28 divisions.
DISplay:WA
VEView<x>:MATH:MATH<x>:VERTical:SCAle
Sets or queries the vertical scale of the specified math in volts per division within
the specified waveview.
NOTE.
WAV
EView<x>
is the specified waveview and must be WAVEView1 .
Group
Display Control
Syntax
DISplay:WAVEView<x>:MATH:M ATH<x>:VERTical:SCAle <NR 3>
DISplay:WAVEView<x>:MATH:M ATH<x>:VERTical:SCAle?
Arguments
<NR3> is the vertical scale of the specified math waveform.
Examples
DISplay:WAVEView1:MATH:MAT H1:VERTical:SCAle 400e-3 sets the scale
to 400 m V per division.
DISplay:WAVEView1:MATH:MAT H1:VERTical:SCAle? might return
:DISPLAY:WAVEVIEW1:MATH:MA TH1:VERTICAL:SCALE 395.00 00E-3
indicating the scale is 395 mV.
DISplay:WAVEView<x>:PLOT:PLOT<x>:AUTOScale
This command sets or queries whether the specified trend gets auto-scaled when
the new data is available within the specified waveview.
Group
Display Control
Syntax
DISplay:WAVEView<x>:PLOT:P LOT<x>:AUTOScale {<NR1>|O FF|ON}
DISplay:WAVEView<x>:PLOT:P LOT<x>:AUTOScale?
Arguments
<NR1> = 0 disables auto-scaling the specified plot in the specified waveview;
any other value turns this feature o n.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-305
