Commands listed in alphabetical order
Examples
CH2:SCAle 200E
-3
sets the scale to 200 mV per division.
CH2:SCAle? might return :CH2:SCALE 500.0 000E-3 indicating the vertical
scaleforthes
pecified channel is 500 mV per division.
CH<x>:SCALERATio
This command sets or returns the scale ration for the specified analog channel.
Group
Horizontal
Syntax
CH<x>:SCALERATio <NR2>
CH<x>:SCALERATio?
Arguments
<NR2> is the scale ration for the specified analog cha nnel.
Examples
CH2:SCALERATio 2.0 sets the scale ratio to 2.0.
CH2:SCALERATio? might return :CH2:SCALERATIO 1.0000 indicating the
scale ratio is 1.0.
CH<x>:TERmination
This command sets or queries the vertical termination for the specified analog
channel. The channel is specified by x.
NOTE. Theavailableargument
s depend on the instrument model and the attached
accessories.
Group
Vertical
Syntax
CH<x>:TERmination <NR3>
CH<x>:TERmination?
Arguments
<NR3> specifies the channel input resistance, which can be specified as 50 Ω or
1,000,000 Ω.
2-204 MSO54, MSO56, MSO58, MSO58LP Programmer
