Commands listed in alphabetical order
TRIGger:{A|B
}:BUS:B<x>:ARINC429A:LABel:HIVALue
This command sets or queries the high value when triggering on an ARINC429
label field. The bus number is specified by x. The trigger condition must be set to
LABel, and th
e label qualifier must be INrange or OUTrange.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Trigger
Syntax
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:LABel:HIVALue <QString>
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:LABel:HIVALue?
Arguments
<QString> is the label value.
Examples
TRIGGER:A:BUS:B1:ARINC429A :LABEL:HIVALUE "XXXX1010" sets the
value to XXXX1010.
TRIGGER:A:BUS:B1:ARINC429A :LABEL:HIVALUE? might return
"XXXXXXXX", indicating that the value is XXXXXXXX.
TRIGger:{A|B}:BUS:B<x>:ARINC429A:LABel:QUALifier
This command sets or queries the qualifier to be used when triggering on label
data for an ARINC429 bus signal. The bus number is specified by x. The trigger
condition must be set to LABel or LABELANDDATA.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Trigger
Syntax
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:LABel:
QUALifier
{EQual|UNEQual|LESSthan|MOREthan
|LESSEQual|MOREEQual|INrange|OUTrange}
TRIGger:{A|B}:BUS:B<x>:ARI NC429A:LABel:QUALifier?
Arguments
Argumentsaretheavailabledataqualifiers.
NOTE. If the trigger condition is set to LABELANDDATA, the label qualifier will
be locked to Equal until the trigger condition is changed again.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-763
