Tektronix MSO56

Commands listed in alphabetical order
Syntax
DISplay:WAVEV
iew<x>:ZOOM:ZOOM<x>:HORizont al:POSition <NR3>
DISplay:WAVEView<x>:ZOOM: ZOOM<x>:HORizontal:POSition?
Arguments
<NR3> is a value from 0 to 100.00 and is the percent of the waveform that is to the
left of screen center, when the zoom factor is 2× or greater.
Examples
DISPLAY:WAVEVIEW1:ZOOM:ZO OM1:HORIZONTAL:POSITION 50 sets the
horizontal position o f the zoom box of waveview1 to 50 so that it is centered
horizontally on the screen.
DISPLAY:WAVEVIEW1:ZOOM:ZO OM1:HORIZONTAL:POSITION? might return
:DISPLAY:WAVEVIEW1:ZOOM:Z OOM1:HORIZONTAL:POSITION 10.0000,
indicating that the horizontal position of the zoom box of waveview 1 is centered
over the first major graticule division.
DISplay:WAVEView<x>:ZOOM:ZOOM<x>:HORizontal:SCALe
This command sets or queries the horizontal zoom factor of the specified zoom in
the specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
ZOOM<x> is the specified zoom and must be ZOOM1 .
Group
Zoom
Syntax
DISplay:WAVEView<x>:ZOOM: ZOOM<x>:HORizontal:SCALe <NR3>
DISplay:WAVEView<x>:ZOOM: ZOOM<x>:HORizontal:SCALe?
Arguments
<NR3> is the amount of e xpansion in the horizontal direction in 1-2-4 increments
of the specified zoom in the specified waveview.
Examples
DISplay:WAVEView1:ZOOM:ZO OM1:HORizontal:SCALe 5 sets the horizontal
zoom factor of zoom1 in waveview1 to 5x.
DISplay:WAVEView1:ZOOM:ZO OM1:HORizontal:SCALe? might return
:DISplay:WAVEView1:ZOOM:Z OOM1:HORizontal:SCALe 10, indicating that
the zoom factor
of waveview1 is set to 10x.
2-312 MSO54, MSO56, MSO58, MSO58LP Programmer
