Commands listed in alphabetical order
Syntax
DISplay:PLOTV
iew<x>:CURSor:VBArs:DELTa?
Returns
The delta T cursor readout value is returned.
Examples
DISplay:PLOTView1:CURSor: VBArs:DELTa? might return
:DISPLAY:PLOTVIEW1:CURSOR :VBARS:DELTA 119.7593E-9 indicating
the
VBARS DE
LTA
is set to 119.76 ns.
DISplay:PLOTView<x>:CURSor:VBArs:UNIts? (Query Only)
This command queries the VBArs cursor readout units of the specified cursor
in the specified view.
Group
Cursor
Syntax
DISplay:PLOTView<x>:CURSo r:VBArs:UNIts?
Returns
The VBArs cursor readout units are returned.
Examples
DISplay:PLOTView<x>:CURSo r:VBArs:UNIts? might return
:DISPLAY:PLOTVIEW5:CURSOR :VBARS:UNITS "V" indicating the units are
Volts.
DISplay:PLOTView<x>:CURSor:WAVEform:APOSition
This command sets or queries the waveform cursor A horizontal position of the
specified cursor in the specified view.
NOTE. In case of XY plot, this command has no effect when used to set the value.
In case of bathtub plot, this command sets or returns the cursor A vertical position.
For all other plots, this command
sets or returns the cursor A horizontal position.
Group
Cursor
Syntax
DISplay:PLOTView<x>:CURSo r:WAVEform:APOSition <NR3 >
DISplay:PLOTView<x>:CURSo r:WAVEform:APOSition?
Arguments
<NR3> is the horizontal cursor A position.
2-258 MSO54, MSO56, MSO58, MSO58LP Programmer
