Command groups
Table 2-29: Horizontal commands (cont.)
Command
Description
HORizontal:FAS Tframe:X ZEro:REF? Returns the sub-sample time between the trigger sample (designated by PT_OFF)
and the occurrence of the actual trigger for the waveform specified by the
DATa:SOUrce command for the reference frame.
HORizontal:FAS Tframe:X ZEro:SELECTED? Returns the sub-sample time between the trigger sample (designated by PT_OFF)
and the occurrence of the actual trigger for the waveform specified by the
DATa:SOUrce command for the selected frame.
HORizontal:MAIn:INTERPRatio?
Returns the main horizontal time base interpolation ratio.
HORizontal:MODE Sets or queries the horizontal mode.
HORizontal:MODe:AUTOmatic:FASTAcq:
RECOrdlength:MAXimum:VALue
Sets or queries the horizontal FastAcq maximum record length.
HORizontal:MODe:AUTOmatic:FASTAcq:
RECOrdlength:MAXimum:ZOOMOVERride
Sets or queries the flag which allows override of the horizontal FastAcq m aximum
record length.
HORizontal:MODe:MANual:CONFIGure Sets or queries which horizontal control (scale or record length) will also change
when the sample rate is adjusted.
HORizontal:MODE:RECOrdlength Sets or queries the record length.
HORizontal:MODE:SAMPLERate Sets or queries the sample rate.
HORizontal:MODE:SCAle Sets or queries the horizontal scale.
HORizontal:POSition Sets or queries the waveform horizontal position, in percent, that is used when
delay is off.
HORizontal:PREViewstate?
Returns the display system preview state.
HORizontal:RECOrdlength Sets or queries the horizontal record length.
HORizontal:ROLL? Queries the horizontal roll mode status.
HORizontal:SAMPLERate Sets o r queries the horizontal sample rate.
HORizontal:SAMPLERate:ANALYZemode:
MINimum:OVERRide
Sets or queries the flag which allows override of the horizontal analyze minimum
sample rate.
HORizontal:SAMPLERate:ANALYZemode:
MINimum:VALue
Sets or queries the minimum sample r ate used by Analysis Automatic horizontal
mode.
HORizontal:SCAle Sets or queries the horizontal scale.
2-36 MSO54, MSO56, MSO58, MSO58LP Programmer
