Maintenance
1132−2/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
5/ 17
4. Removal of bearing covers No. 2 and following
D Place thrust device 94110 as described in section 2.
⇒ Screw RUD-eye bolt M20 ’RC’ into the guide shoe and tighten it with 115 Nm.
⇒ Fasten lifting ring 94332 (with shackle 94332a) to cylinder block 14 using
screws 15 which must be tightened with a torque of 200 Nm.
D
018.597/09
14
94332
15
RC
94332a
50−D / 2010
Removal and Fitting of a Main Bearing
