Maintenance8447−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 4
2.1 Removal of servo oil piping 3
⇒ Loosen screws 4.
⇒ Push flanges 5, 5a back till they are no more engaged, so that servo oil piping
3 can be removed.
2.2 Removal of servo oil piping 2
⇒ Loosen screws 4a and push flanges 5 back.
⇒ Loosen screws 6 and remove them together with intermediate piece 7.
⇒ Loosen screws 4b and remove servo oil piping 2.
C
III
I
II
013.518/0
5
5a
15 11
V - V
V
V
I
013.514/05
1
5a
4b
2
013.515/05
IV - IV
013.517/05
013.519/05
013.513/05
013.516/05
II
III
4b
7
6
5
345
IVIV
5
4
3
2
4a
8
OE
DF
14
2010
S
ervo Oil Piping: Removing, Fitting and Regrinding
