Wartsila RT-flex50-D User Manual

Maintenance
2124−2/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
3/ 9
2. Removal and fitting of cylinder liner with water guide jacket
⇒ Loosen screws 5.
⇒ Loosen screws 10 and remove them together with angle plates 11 and con-
nection pieces 9 from water guide jacket 3 (view II-II).
B
016.505/08
I - I
FUEL SIDE
II - II
I I
II
II
57a
6
567
1
20 3
10
9
8
11
19
1
3
2
2010
Removal and Fitting of Cylinder Liner or Water Guide Jacket
