Wartsila RT-flex50-D User Manual

Maintenance9223−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
10/ 22
008.739/01
− Retaining ring 29 (using tap holes ’GL’) t
o-
gether with sealing ring 30 and O-ring 60.
− Distance ring 31.
− Ball bearing 32, distance ring 33, distanc
e
sleeve 34 and disc springs 35.
− Circlip 36.
− Disc 37 together with ball bearing 32a.
Parts to be removed in the following sequence:
N
31
30
29
34 35
33 3232a3736
6014
x
GL
2011
C
rank Angle Sensor Unit: Dismantling, Assembling and Adjusting
