Maintenance3603−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 3
⇒ Loosen screws 2.
⇒ Loosen screws 3.
⇒ Lower ring holder 4 together with sleeve
5
(Fig. ’D’).
⇒ Turn crank to B.D.C.
⇒ Remove inside pipe 6 together with sleeve
5
and ring holder 4 downwards.
If the engine should be operated with remove
d
connecting rod, flange 94337b must be used f
or
blanking off the oil inlet bore.
2. Blank off oil inlet pipe
C
013.414/05
013.415/05
5
4
3
6
7
2
8
9
11 10
10
II
III
D
E
701.013.416
013.416/05
013.417/05
4
7
94337b
5
6
III
2
6
Piston Cooling and Crosshead Lubrication: Removal and Fitting of Inside Pipe
