Maintenance3326−2/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
6/ 7
⇒ Rotate the crosshead pin 90_ around its axi
s,
connect it to spur-geared chain block 9 an
d
then remove it from the engine.
3. Removal of guide shoes
⇒ Connect lifting tackle ’HZ’ to RUD-eye bo
lt
’RC’ on the guide shoe ’free end’ and swivel
it
into the centre of the cylinder (Fig. ’I’).
⇒ Remove lifting tackles H
3
.
D Proceed in the same way as mentione
d
above for the guide shoe ’driving end’, how
-
ever using lifting tackles ’HZ’ and H
4
.
H
I
013.245/05
H
4
H
3
H
4
H
3
HZ
HZ
94666
RC
5
I
I
I - I
013.246/05
013.247/05
013.248/05
94324
9
5
DRIVING END
2010
Removal and Fitting of a Crosshead Pin
