Maintenance0008−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 3
General Arrangement with Two Turbochargers:
FREE END
DRIVING END
Thrust Bearing Pads
FUEL SIDE
EXHAUST SIDE
Rail Unit
Clockwise Rotation
Counter-clockwise
Rotation
Supply Unit
Turbocharger 1
Cylinder
Numbering
Auxiliary
Blower 2
Auxiliary
Blower 1
018.749/09
65432871
1 2 3 4 5 6
7
Turbocharger 2
9
Main Bearing
Numbering
2010
E
ngine Numbering and Designations
