6.2 Torque amplifier applications
The following figures show the torque amplifier application for every single waisted
screw 7.
Backing rod 23 or 24 is drawn in the required position:
− with continuous lines for tightening and
− with broken lines for loosening procedure.
O P
Q R
22
22 24
20
94566c
013.069/05
24
BEARING COVER NO.
1
BEARING COVER NO.
2
20
94566c
2010
S
upply Unit: Removal and Fitting of Camshaft and Bearing Shells
