Wartsila RT-flex50-D User Manual

Maintenance
5552−4/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
1/ 3
Tools: Key to Illustrations:
1 Lifting tool 94557 1 Supply unit 9 Housing
(for transporting supply unit) 2 Fuel pump 10 Spray nozzle
Devices 94430 3 Cover 11 Screw with distance sleeve
(depending on number of cylinders) 4 Dowel pin 12 Holder
5 Screw
6 Screw
7 Screw HZ Lifting tackle
8 Head screw RC RUD-eye bolt
1. Removal
D Cut out of fuel pump 3 by means of device 94430 (see 5556−2 in the Operat-
ing Manual).
Remark: Pay attention to General Guidelines for Lifting Tools 0012−1.
⇒ Remove all pipings and electric connections if necessary.
⇒ Remove cover 3.
⇒ Withdraw dowel pins 4.
A B
013.042/05
11
12
2
94430
1
12
3
9
S
upply Unit
R
emoval and Fitting
2010
