Wartsila RT-flex50-D - Hydraulic Jacks and Pumps Arrangement and Application

Maintenance
9403−2/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
1/ 3
A
B C
3
9
3
1
3
4
5
3
6
3
5
2
14
016.623/08
8
7
H
16
15
3
WCH00724
A = Tensioning / loosening of tie rods, waisted studs to exhaust valve cages, top
and bottom end bearings to connecting rod, piston rod screwing and waisted
studs to piston crown
B = Tensioning / loosening of waisted studs to cylinder cover
C = Tensioning / loosening of foundation bolts and of engine stays
H
ydraulic Jacks and Pumps
A
rrangement and Application
2011-12
