8. Removal and fitting of compression spring
008.748/01
008.747/01
008.746/01
V
8.1 Preparation
⇒ Remove oil inlet ’OE’ (Fig. ’A’).
⇒ Dismantle crank angle sensor drive according
to
section 4.
⇒ Remove screws 47 and housing 46.
⇒ Remove screws 48 and connecting unit 49.
⇒ Remove screws 44 and withdraw waisted screw 2
0
from the lever 43.
47 46
20
43
40
50
48a
48
51 44
I - I
W
I
I
43
44
51 48
50
49
20
2011
