Wartsila RT-flex50-D - Numbering of Bearings

Maintenance5552−2/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 11
⇒ Remove covers 4 and 5.
⇒ Remove servo oil pump 2 and spray nozzle
6
(see 5552−1).
B
012.980/05
5
2
4
6
2. Numbering of bearings
Bearing No. 2 is designed as thrust bearing, th
e
other ones as normal bearing.
Remark: All bearing covers 8 and 9 are machine
d
together with housing 10, therefore never inte
r-
change them! They must be marked according
ly
before their removal.
C
I - I
I
I
012.981/05
10
7
9
10
7
11
17
8
5
4
3
2
1
2010
S
upply Unit: Removal and Fitting of Camshaft and Bearing Shells
