Wartsila RT-flex50-D - Page 498

Maintenance9403−5/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
14/ 38
94272
94272a
94272b
94272c
1
1
1
1
OBEL test bench
for checking and adjusting of:
− injection valve
− relief valve (cylinder cover)
− fuel overpressure control valve 3.52
X = 1458 mm
including:
Valve holder
for fuel overpressure safety valve
X = 149 mm
Connecting piece
for injection valve
X = 124 mm
Valve holder
for relief valve to cylinder cover
X = 66 mm
X
X
94272a
94272b
X
013.579/05
94272c
X
94279 1 Gauge
for checking wear and burn scar on
exhaust valve seat
X = 150 mm
002.563/98
X
94280
94280a
1
1
Adjusting disc
for adjusting injection valve
X = 10.2 mm
Adjusting disc
for adjusting injection valve
X = 10.5 mm
X
013.581/05
94292 1 Gauge
for checking wear on disc of
exhaust valve spindle
X = 160 mm
X
013.582/05
2010
Standard Tools
